MODEL |
POF-1000UA |
|
CAPACITY |
1000VA/500W |
|
INPUT |
|
|
Voltage |
110/115/120VAC |
|
Voltage Range |
86~144VAC |
|
Frequency |
50Hz or 60Hz (auto sensing) |
|
OUTPUT |
|
|
Voltage |
110/115/120VAC |
|
Voltage Regulation (Battery Mode) |
±10% |
|
Frequency |
50Hz or 60Hz |
|
Frequency Regulation (Battery Mode) |
±1Hz |
|
Waveform (Battery Mode) |
Simulated sine wave |
|
Outlets |
12 Outlets (6 battery backup + surge & 6 surge only ) |
|
Typical Transfer Time |
2~6ms (typical) |
|
BATTERY |
|
|
Battery Type & Quantity |
12V/9Ah x 1 |
|
Backup Time (Basic PC) |
Up to 30 minutes |
|
Typical Recharge Time |
|
|
PROTECTION |
|
|
Full Protection |
Over discharge protection & short circuit protection |
|
Tel/Fax/Network Suppression |
RJ-11/45 combo port |
|
Lighting & Surge Protection |
175 Joules |
|
USB |
|
|
Charging Interface (2 Ports) |
5VDC/2.1Amp (max.) charge current |
|
Software de monitoreo |
N / A |
|
FÍSICO |
|
|
Dimensión (D x W x H) (mm / in) |
290 x 94 x 170 / 11,4 x 3,7 x 6,7 |
|
Peso neto (kg / lb) |
5.9 / 13.1 |
